Radar velocity meter

ชื่อสินค้า : Radar velocity meter

รหัส : RKL-05

แบรนด์ : RIKA

ไฟล์เอกสาร :

Download

รายละเอียด :

PRODUCT DESCRIPTION

RKL-05 radar velocity meter is a non-contact radar velocity measurement device, which can effectively monitor.Surface velocity of water flow in various channels and natural channels.The product is easy to install and maintain, and easy to operate.Widely applicable to water.In the fields of literature, flood control and drainage, environmental pollution monitoring, etc., 7x24 hours online monitoring is realized

- Excellent stability

- Fast response

- Wide temperature range compensation

- High accuracy

- Anti-corrosion material optional

- Strong resistance to interference

SPECIFICATIONS

Item	Technical specifications
frequency	24GHz
range	0.1 ~ 20 m/s (It has to do with the flow pattern)
Accuracy	±0.01m/s ；±1%FS
Resolution	0.01m/s
beam Angle	12 °
Pitch Angle	30 ~ 70 °
Intelligent perception and compensation of attitude Angle	Accuracy±0.5°；Resolution±0.1°
Supply	DC6 ~ 30V (suggested use 12 v)
Power consumption	Working current :40mA@12V; Standby current :5mA@12V
Output	RS485(MODBUS-RTU)
Working temperature	- 40 ℃ ~ + 80 ℃
Protection grade	IP68
Product size	10510560mm
weight	0.45Kg
Cable length	10 m(default), customizable
